Rod Machine 240




Product Introduction:

The charcoal rod machine 240 is a latest charcoal briquette machine which can compress sawdust, bamboo, wood, shells, straw and other waste biomass materials into rod briquettes. After carbonization, users can get rod charcoal rods.

rod-making-machine

Raw material can be sawdust, wood branches, wood residues, rice husk, sunflower shell, peanut shell, corn stalk, straw, bamboo, cotton stalk, coconut shell, olive waste, furfural dregs, bagasse, corncob, corn stalk, shurbs or other agricultural wastes.


Compared with common charcoal rod machine, the charcoal rod machine 240 has larger capacity with power saving 9 KWH per hour, 72 KWH per shift.
Technical Parameters:

Machine Model
50 80 240
Capacity
150--180kg/h
230--280kg/h
230--280kg/h
Power
15kw
18.5kw
22kw
Output Products Diameter
50mm
50mm
80mm
Machine Dimension
1.7*0.75*1.35(m)
1.8*0.8*1.6(m)
1.85*0.75*1.45(m)
Weight
850kg
900kg
1000kg
Raw Materials
Sawdust, wood chips, biomass, etc
Briquette Shape
Round, square, hexagonal sticks with holes inside















Video Show:
